Sennheiser XSW 1-825-GB Handheld Radio Mic System

Item Details

Raise your voice. Go for XS WIRLESS 1 and rely on a solid wireless transmission with up to 10 compatible channels in a stable UHF band. The XS WIRELESS 1 VOCAL SET is an easy to use all-in-one wireless system for singers and presenters, excellent for live sound featuring Sennheiser’s renowned evolution microphone capsule, e825 (dynamic, cardioid), to get started. The set includes an intuitive stationary receiver for quick setup and hassle-free handling, as well as a vocal microphone and microphone clamp.

Features

• Excellent live sound featuring Sennheiser’s renowned evolution microphone capsules
• Automatic frequency management and synchronization via remote channel for easy setup
• Up to 10 compatible channels
• Excellent live sound featuring Sennheiser’s renowned evolution microphone capsules (e825 or e835)
• Antenna-switching diversity reception
• Integrated antennas
• Automatic frequency management and synchronization via remote channel for easy setup
• Selectable UHF frequencies within a large bandwidth
• Up to 10 compatible channels

Technical Specifications

Dimensions	approx. 200 x 42 x 127 mm
THD, total harmonic distortion	≤ 0.9%
Weight	approx. 340g approx. 245g
Pick-up pattern	cardioid
Signal-to-noise ratio	≥ 103 dBA
RF output power	10 mW
Switching bandwidth	up to 24 MHz
Operating time	approx. 10 hrs
Modulation	wideband FM
Power supply	Receiver: 12 V DC nom. / 300 mA Microphone: 2 AA size batteries, 1.5 V
Output voltage	1/4“ (6.3 mm) jack socket (unbalanced): +6 dBu, XLR socket (balanced): +12 dBu
Housing	rugged ABS housing
Dynamic range	dynamic
Frequency	8 frequency banks, each with up to 10 factory-preset channels
Frequency range	GB: 606-630 MHz
Sensitivity	< 3 μV at 52 dB(A)rms S/N
Squelch	adjustable from 3 dBμV to 28 dBμV (combined with pilot tone)
Synchronization	2.4 GHz, Low Power OQPSK (only active during synchronization)
Input sensitivity	1.5 mV / Pa
AF frequency response	Receiver: 50 to 16,000 Hz (–3 dB) SKM 825: 80-14,000 Hz SKM 835: 80-16,000 Hz
Adjustment Range Transmitter	0 to -30 dB, adjustable in 10 dB steps
Audio adjustment range	45 dB, adjustable in 5-dB steps
Line / Mic level	20 dB, switchable
Temperature Range	operation: 0°C to +40°C, storage: –20°C to +70°C
Receiver Principle	double superheterodyne
Diversity principle	Antenna switching diversity via internal antennas
