Hi-lights Online Store » ADJ ElectraPix Bar 8

Key Features

0.5 metre battery or mains powered batten wash
8x 20 watt Hex Color LED (RGBAL+UV)
Built in wireless DMX, 5 pin DMX or included remote control

Available to buy

Price (inc VAT)	£689.00

MPN:	1226100502

Weight:

8 kg

Delivery Charges

Mainland UK (Free)
Scottish Highlands (Free)
Collect in person (Free)

Available mid October

Enquire about this item

Item Details

The ADJ Lighting ElectraPix Bar 8 is a cutting-edge, 0,5-Meter battery powered, wireless DMX lighting solution. Packed with advanced features, this fixture boasts eight 20-Watt Hex Color LED (RGBAL+UV), providing unparalleled control and creativity. Powered by either batteries or wall outlets, it offers 5 hours of standard battery operation or an extended 10-hour saver mode.

With individual pixel control, built-in foreground and background LED programs, and a variable white color temperature range, the ElectraPix Bar 8 ensures dynamic lighting possibilities. Its color-calibrated LEDs, user-selectable dim modes, and electronic strobe/dimming enhance versatility.

Designed for adaptability, the IP65-Rated housing, OLED digital display, L Track system, and adjustable feet make installation and customization a breeze. The fixture’s control options include DMX512, Aria X2 Wireless DMX, Bluetooth, RDM compatibility, and an included UCIR24 wireless remote.

The ElectraPix Bar 8 guarantees reliability with certifications such as CE, FCC, and pending cETLus, while its IP65-Rating ensures durability in various environments. Included accessories like the outdoor locking power cable and UCIR24 remote, along with optional add-ons, make this fixture a comprehensive lighting solution for professionals. Elevate your lighting design with the ElectraPix Bar 8, where innovation meets performance.

Features

8 Pixel, Hex Colour LED (RGBAL+UV) LED Bar
Battery or Wall Powered
5 Hour Standard Battery Operation and 10 Hour Saver Battery Operation (Menu Option)
Individual Pixel Control
Built-In Foreground LED Programs
Built-In Background LED Programs
Variable White Colour Temperature Control (2,700K ~ 9,900K)
English & Spanish User Menu
Built-In Alarm
Colour Calibrated LED’s
User Selectable LED Refresh Rates (900Hz ~ 25K)
6 User Selectable Dim Modes
4 User Selectable Dim Curves
Electronic Strobe (0.3Hz ~ 11Hz)
Electronic Dimming

Source:

(8) 20W Hex Colour RGBAL+UV Foreground LED’s
(32) 0.2W RGB Background LED’s
50,000 Hour Average Life*

*May vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.

Optical:

2,300K ~ 9,900K White Colour Temperature Range
17° Beam Angle
45mm Lens Diameter x8

Physical:

IP65 Housing
OLED Digital display
L Track system for locking accessories / rigging
Glare Shield
Diffusion Filter slot
Angle adjustable feet
Horizontal slide lock to attach additional ElectraPix Bar 8 or ElectraPix Bar 16

Control:

DMX512
Aria X2 Wireless DMX
Bluetooth
RDM and RDM Net Compatible
IR (Includes UCIR24 wireless remote)
(4) DMX Channel Modes (5, 6, 9,13, 21, 24, 48, 52 & 66 Channel modes)
On-board Manual Control Mode
Primary / Secondary Mode

Connections:

5pin XLR Outdoor DMX In/Out Sockets (Must be used with STRxxx, 5pin DMX cables to create IP65 seal)
Outdoor Locking Power Sockets
Battery Charging Socket

Dimensions & Weight:

Length: 85.7mm, Width: 590.3mm, Height: 191.2mm
Weight: 8 kg

Power:

AC100-240V/50Hz-60Hz Input
60W Power Consumption
Link 28 pieces @ 230VAC

Battery:

Rechargeable Lithium ion
Battery Capacity: 7,000mAh
Battery Voltage: 22.2V
Charge Time: 6 Hours (To Full)
5 Hour Standard Operation at Full Output and 10 Hour Saver Mode Operation at Full Output Selectable in the menu
Battery Cycles: 500

Thermal:

Ambient Operational Temperature: -20°C to 45°C
Storage Temperature: -30°C to 45°C

Certifications & IP Rating:

CE
cETLus (Pending)
FCC
IP65

Included Accessories:

(1) Outdoor Locking Power Cable
(1) UCIR24 Remote
(1) 20° Diffusion Filter

Optional Accessories:

ElectraPix Bar FB
LTrack A2 (LTrack Adapter Only)
LTrack CA2 (LTrack Adapter with Narrow Clamp)
