Hi-lights Online Store » ADJ Ultra Beam Bar 12CW

Key Features

12 x 20 watt ultra bright 6200K Cool White LEDs
Individual pixel controllable in 12, 14 and 19 channel DMX modes
13 Built-In Programs

Available to buy

Price (inc VAT)	£315.00

MPN:	1226200080

Weight:

3.4 kg

Delivery Charges

Mainland UK (Free)
Scottish Highlands (Free)
Collect in person (Free)

Enquire about this item

Item Details

The ADJ Ultra Beam Bar 12CW is a powerful, versatile LED lighting solution designed for energetic indoor environments like stages, clubs, and entertainment venues. Measuring 1 meter, this sleek, linear bar is equipped with twelve high-performance 20 watt cool white LEDs, offering an impressive 6200K color temperature and 5-degree beam angle per pixel for sharp, precise illumination.

With individual pixel control via DMX and a wide range of built-in programs, including synchronized and random strobe effects, the Ultra Beam Bar 12CW allows for stunning visual effects and dynamic lighting design. The fixture offers 13 built-in programs and a customizable strobe rate from 0.3Hz to 11Hz, giving you full creative control over your lighting setup.

For added convenience, the Ultra Beam Bar 12CW includes the UC-IR remote for easy operation and supports DMX, RDM and RDM Net for seamless remote monitoring and control. It also features 0-100% electronic dimming, multiple dim modes and dim curves to suit any environment, from stages to TV sets.

Like other ADJ Ultra Bar Series fixtures, the Ultra Beam Bar12CW has magnets on the end caps allowing seamless fixture alignment when using multiple fixtures together. With its compact design, easy installation, and linkable power capabilities, the Ultra Beam Bar CW12 is the ideal lighting solution for any professional lighting setup.

Features

Light Source:

12 x 20W Ultra bright (6200K, Cool White) LEDs
Long Life LEDs (Rated at approximately 50,000 hrs.)
1340 Lumens
5° beam angle (Per pixel)
Pixel Pitch: 85.5mm

Features:

12 Sharp Beams
Primary / Secondary stand alone control mode
13 Built-In Programs
Compatible with the ADJ UC-IR remote. Operates at a distance of up to 32.8 feet (10 meters). UC-IR included.
Horizontal Magnetic Alignment feature (Built-In)
DMX, RDM and RDM NET Compliant
Pixel Flip mode

Control:

OLED Display with 4-buttons
5 DMX Channel Modes: 1, 3, 12, 14, & 19 Channels
Individual pixel controllable in 12, 14 and 19 channel DMX modes
5 operational modes: Manual Pixel, Manual Program, Program Sound Trigger, and DMX-512 Modes
LED Refresh Rate: 1.9KHz
6 selectable Dim Modes (Standard, Stage, TV, Architectural, Theatre & Stage 2)
4 selectable Dim Curves (Square, Linear, Inv. Square & S. Curve)
Built-In Microphone for sound trigger
Synchronized, pulse and random strobing
Electronic Dimming: 0-100%

Connections:

Linkable: DMX via 5-pin XLR cable
Indoor Locking power In/Out to daisy chain power
Safety Loop

Electrical:

Multi-voltage operation: AC 100V-240V 50/60Hz
Power Draw: 60W
Daisy-chain power link (Up to 32 can be linked @230V)

Dimensions / Weight:

Dimensions (LxWxH): 75x1082x106.7mm
Weight: 3.4kg

Certifications / IP Rating:

IP20

Environment:

Operational Temperature Range: -20°C ~ 45°C

Storage Temperature: -20°C ~ 45°C

What’s Included:

(1) Indoor Locking Power Cord
(1) UC-IR
(1) 5° Beam Filter
(1) Safety Cable
Includes mounting brackets to set on the ground or to mount a clamp to for truss mounting

Optional Accessories:

(1) 1×40° Linear Diffusion Lens
