ADJ Vizi Beam RX2 (Beam Fixture)

Item Details

The ADJ Vizi Beam RX2 is a compact yet powerful moving head beam fixture designed for lighting professionals who need high-output performance in a lightweight and versatile format. Built around a 100W Osram Sirius HRI discharge lamp, the fixture delivers sharp aerial effects, fast movement, and advanced beam features suitable for touring productions, live events, clubs, theatres, and installation environments.

High-Intensity Beam Output

At the heart of the Vizi Beam RX2 is a 100W Osram Sirius HRI long-life discharge lamp with a 9000K colour temperature and a rated lifespan of approximately 6,000 hours. The fixture produces a razor-sharp 2-degree beam that is capable of delivering highly concentrated aerial effects across long distances. This narrow beam angle makes the RX2 ideal for concert touring, nightclubs and entertainment venues, festival stages, touring productions, corporate events and architectural installations.

Creative Features for Dynamic Lighting Design

The Vizi Beam RX2 includes an extensive range of creative tools that allow lighting designers to create layered and dynamic effects. Key features include:

• 14 dichroic colours plus white
• CTO, CTB, and UV filters
• 15 static gobos plus open
• GOBO shake effects
• Frost filter for wash-style effects
• Motorised focus with 16-bit fine control
• Smooth 0–100% dimming
• Variable strobe effects

One of the fixture’s standout additions is its dual rotating prism system. The RX2 features:

• 16-facet circular prism
• 4-facet linear prism
• Prism overlay functionality

These prism combinations allow a single beam to multiply into complex aerial patterns that enhance depth and motion during live performances. A frost filter also gives you the ability to soften the beam and create broader wash-style effects when needed.

Fast and Precise Movement

The Vizi Beam RX2 uses high-speed 3-phase pan and tilt motors designed for rapid and accurate positioning. The fixture supports 540° pan, 270° tilt and 16-bit fine pan and tilt control, making it quick energetic live productions where quick transitions and sharp positioning are essential.

The compact fixture dimensions and lightweight construction also make it ideal for truss installations and touring rigs where weight and space efficiency are important. The fixture weighs approximately 7.5kg to 9.9kg depending on regional specifications.

Wireless Control and Professional Connectivity

The Vizi Beam RX2 includes modern control features, including:

• On-board wireless DMX
• DMX512 and RDM protocol support
• 16 and 20-channel DMX modes
• Aria X2 wireless management compatibility
• 5-pin DMX input/output
• Outdoor-rated locking power connections for daisy chaining

A colour LCD display with a 4-button menu system simplifies fixture setup and configuration, while over-the-air firmware updates help keep the unit current with future improvements.

Built for Touring and Live Production

The Vizi Beam RX2 has been designed specifically for high-energy production environments. Its durable construction, compact size, and advanced feature set make it suitable for rental companies, touring crews, and permanent installations alike. The fixture’s portability allows multiple units to be used without placing excessive weight on trusses, making it especially attractive for mobile production companies and venues with limited rigging capacity.
